Power | |
AC Power | 100-240V AC, 50/60 Hz |
Rated Power | 800W@220V |
Optics | |
Lamp | 400W LED |
Rated life | 20000h |
LUX | 5m 168000lm |
Beam angle | 3°~45° |
Effects | |
Horizontal scanning | 540° |
Vertical scanning | 270° |
Shutter | 0~30HZ |
dimming | 0-100% coarse and fine control |
Color | 8 Colors+White light, half color function CMY+CTO |
Fixed Gobo | 12 fixed +white light |
Rotation Gobo | 7 glass gobo ,each glass gobo can be independent positive and negative rotation |
Prism System | 4 prism and 8 prism, each prism can be independent positive and negative direction |
Focus | DMX linear adjustment |
Macro function | console reset function,self-walk mode,master-slave mode |
Control | |
Control and Programming | DMX512,With RDM function,software can be upgraded online,dial the address code |
DMX channels | 22CH/26CH |
Physical characteristics | |
Protection Rating | IP20 |
Housing | high temperature resistant flame |
Retardant | plastic |
AC Power in/thru | Neutrik PowerCon |
DMX data in/out | 3-pin locking XLR |
Weight | 23.5kg |
ambient Temperature | -20℃~40℃(-4°F~104°F) |
Lamp size | 383x274x668mm |
Package size | 750x360x470mm |
