KINGKONG Console
256A DJ Disco/Stage Lighting Console
- Brand Name : King Kong
- Model Number : KK-256
- Type : dmx controller
- DMX channel : 256
- Voltage: AC100-240V
- Power : AC100V-240VB/50-60Hz
Product Details
KINGKONG 256A Console /DJ Disco Console/ for Stage Lighting
Specification
| DMX Channel | 256 |
| Power | AC100V-240V/50-60HZ |
| Weight | 9.5kg in flight case, 4.5kg in carton |
| Size in flight case | 540*270*180mm |
| Size in Carton | 540*260*128mm |
| Time control of Scene | HTP, LTP |
| USB Memory | FAT32 supported |
| Built-in Shape | 35 |
| Channels for each fixture | 32 |
| Fixture | 16 |
| Dimmer | 64 |
| Playback | 80 |
| Playbacks to run Simultaneously | 16 |
| Scene step | 600 |
| LCD display with back light | Yes |
| Bilingual operation | Yes |
| Scene and dimmer by slider | Yes |
| Flash Scene | Yes |
| Channel slope modification | Yes |
| X/Y value by wheel | Yes |
| Real time blackout | Yes |
| Dimmer by slider | Yes |
Main faction:
①DMX 512/1990, up to 256 Dmx channels, output with optical isolated
②Up to 12 intelligent fixtures with 16 channels can be controller.
③It is featured with built-in shape effects of pan/tilt circle, RGB rainbow and varieties of chases, etc.;
④16 chases and 10 built-in shapes can be output simultaneously
⑤48 playbacks can be store as chase, scene and Cue list. Up to 100 steps can be store in chase.
⑥32 macros as shortcuts to run playback combinations.
⑧LCD display with backlight.
1.Patch
①King Kong 256 can operate fixtures directly without patching; The default channel number is 16 for each fixture.
②When the fixtures are patched, then, you can make use of the built-in programs to get more conveniences and flexibility.
2.Language Selection
The Operation languages are available in Chinese and English.
3.Update
It’s easy to update.
a.Copy the updated file to a U-Disk and insert it to the USB port of the console.
b.Power on the console. It starts searching the update firmware in the U-Disk; Once detected, it prompts to update or not.
